Width: 76.2 mm
Height: 38.1 mm
Length: 127 mm
Industry: Medical, Industrial
Approvals: CSA/UL60950-1, EN60950-1, IEC60950-1
Compliance: CSA/UL60950-1, EN60950-1, IEC60950-1
Efficiency: 91 %
Unit Weight: 500 g
Output Power: 550 W
Input Voltage: 90 VAC to 264 VAC, 390 VDC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 1 Output
Power - Convection: 150 W
Power - Forced Air: 550 W
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 6.25 A
Output Voltage-Channel 1: 24 VDC
Operating Temperature Range: - 40 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 40 C
