Parameter Measured
Particle size distribution: Suspension, emulsion, dry powders
General
Principle: Laser diffraction technologies
Analysis: Mie scattering theory and Fraunhofer diffraction theory
Typical measurement time: Less than 10 seconds
Measurement Performance
Measuring range: 0.1 - 1000μm
Accuracy: ≤1% (NIST certified standards)
Repeatability: ≤1% (NIST certified standards)
Number of size classes: ≤100 (adjustable)
Feeding mode: Automatic wet circulation
Special functions: SOP settings, refractive index measurement, sample ratio calculation
Main Device
Optical system: Patented DLOS (Dual Lens Optical Systems)
Laser: High-power fiber semiconductor laser (10 mW/635 nm)
Detector: 86 photodetectors (forward, lateral and backward arrangements)
Measuring angle: 0.031 - 159°
Dispersion module
Circulation speed: 300 - 2500 r/min
Circulation flow rate: 3,000 - 8,000 mL/min
Ultrasonication: Dry run protection, Max 50 W (adjustable)
Circulation tank capacity: 600 mL
Software
Conformity: 21 CFR Part 11, ISO 13320, CE
Reports: Customizable reporting
System Parameters
Dimensions (L x W x H): 660 x 420 x 320 mm
Weight: 38 KG
Voltage: DC 24V, 221 W
Computer Configuration (Recommended):
Computer interface: At least one high-speed USB 2.0 or USB 3.0 port required
Operating system: Windows 7 or higher
Hardware specification: Intel Core I5, 4GB RAM, 250GB HD
