Width: 5.8 mm
Height: 8.6 mm
Length: 5.8 mm
LED Size: T-1 3/4 (5 mm)
Lens Color: Colorless
Lens Shape: Dome
Unit Weight: 289.300 mg
Power Rating: 80 mW
Configuration: Common Cathode
Viewing Angle: 40 deg
Mounting Style: Through Hole
Lens Dimensions: 5 mm
Lens Transparency: Diffused
Illumination Color: Red, Green
Luminous Intensity: 35 mcd, 35 mcd
If - Forward Current: 20 mA
Vf - Forward Voltage: 2 V, 2.1 V
Wavelength/Color Temperature: 625 nm, 568 nm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 25 C
