BK Precision 732A Digital Sound Level Meter

Name: BK Precision 732A Digital Sound Level Meter
Brand: BKPRECISION
Availability: OutOfStock

ManufacturerBKPRECISION(View more products from this manufacturer)

Model732A

OriginTaiwan

Warranty12 months

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Frequency range: 31.5Hz ~ 8KHz
Measuring level range: 30 ~ 130dB
Frequency weighting: A / C
Microphone: 1/2 inch electret condenser microphone
Display: LCD
Digital display: 4 digits
Resolution: 0.1dB
Display Update: 0.5 sec.
Analog display: 50 segment bargraph
    Resolution: 1dB
Display Update: 50 mS
Time weighting: FAST (125mS), SLOW (1 sec.)
Level ranges: Lo: 30 – 80 dB
Med: 50 – 100 dB
Hi:   80 – 130 dB
Auto: 30 – 130 dB
Accuracy: ±1.5dB (under reference conditions @ 94dB, 1KHz)
Alarm function: “OVER” is when input is more than the upper limit of range.
“ UNDER ” is when input is less than the lower limit of range.
MAX/MIN hold: Holds readings the Maximum and Minimum Value.
AC output: 1 Vrms
DC output: 10mV / dB
Power supply: One 9V battery
Electromagnetic Compatibility:
RF field = 3V/m
Total accuracy = specified accuracy + 0.5dB
Dimensions (L x W x H): 10.8 × 2.5 × 1.2inch (275 × 64 × 30mm)
Weight: 285g
Accessories: 9V battery, carrying case, Screwdriver, Instruction manual, Windscreen

Whether you are testing for OSHA compliance, quieting equipment, or monitoring the roar of a stadium crowd, B&K Precision Sound Level Meters can get the job done. The model 732A Sound Level Meter provides 30~130 dB capability in three convenient measurement ranges Low, Med and Hi with an accuracy of ±1.5 dB. The meter meets the IEC 651 Type II and includes frequency weighting A & C and fast and slow time weighting. Two auxiliary ports provide either AC output, 1Vrms full scale, or DC output, 10mV /dB. With the model 732A, B&K Precision can meet all your sound testing needs.
