Width: 4 mm
Height: 1.2 mm
Length: 4 mm
Core Type: Wirewound
Q Minimum: 6
Shielding: Semi-Shielded
Tolerance: 20 %
Inductance: 3.3 uH
Application: Automotive
Termination: Standard
Unit Weight: 77 mg
Core Material: Ferrite
Qualification: AEC-Q200
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 1.7 A
Saturation Current: 1.4 A
Maximum DC Resistance: 70 mOhms
Self Resonant Frequency: 60 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
