Width: 7.6 mm
Height: 2.9 mm
Length: 7.8 mm
Core Type: Wirewound
Shielding: Shielded
Tolerance: 20 %
Inductance: 5.6 uH
Application: Power
Termination: Standard
Unit Weight: 1 g
Core Material: Ferrite
Qualification: AEC-Q200
Mounting Style: PCB Mount
Termination Style: SMD/SMT
Maximum DC Current: 7.3 A
Saturation Current: 12.5 A
Maximum DC Resistance: 33.2 mOhms
Self Resonant Frequency: 16 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
