Width: 6.2 mm
Height: 2.5 mm
Length: 6.5 mm
Core Type: Wirewound
Q Minimum: 8
Shielding: Shielded
Tolerance: 30 %
Inductance: 2.2 uH
Application: Power
Termination: Standard
Unit Weight: 300 mg
Core Material: Ferrite
Mounting Style: PCB Mount
Test Frequency: 7.96 MHz
Termination Style: SMD/SMT
Maximum DC Current: 3.4 A
Saturation Current: 2.35 A
Maximum DC Resistance: 24 mOhms
Self Resonant Frequency: 65 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
