Digital Communications I/O: EtherNET/IP
Mechanical Connection: 9/16 - 48 X 3/4” Sanitary
Valve Type: Normally closed
Analog Communications I/O: None
Revision Level: RevB
Performance:
Full Scale Flow Range (N2, Eq. 0ºC Ref): 0.003 - 50 slpm
Flow Accuracy—17025 Certified Devices: ±0.6% of S.P. (20 - 100% F.S.), ±0.12% F.S. (<20% F.S.)
Flow Accuracy: ±0.9% of S.P. (20 - 100% F.S.), ±0.18% of F.S. (<20% F.S.)
Control Range N2, eq.: 100:1 for F.S. from 1 - 50 slpm (50:1 for all other F.S. flows)
Repeatability & Reproducibility: 0.20% S.P
Linearity: Included in accuracy
Response Time: <1 second
Zero Stability: <+0.2% F.S. per year
Temperature Coefficient: Zero: <0.05% of F.S. per °C Span: <0.1% of S.P. per °C
Attitude Sensitivity: <0.2% F.S. maximum deviation from specified accuracy after re-zeroing
Ratings
Operating Temperature Range: (-14) - 65°C (7 - 149°F)
Minimum Pressure Differential: 5 psi / 0.35 bar
Maximum Pressure Differential: Application specific up to 1500 psi / 103.4 bar
Leak Integrity: 1x10^-9 atm. cc/sec He
Valve Shut Down: <1% of F.S. standard; improved shut off available with Biotech package
For more details, see datasheet.
