Printing Technology: Thermal transfer, direct thermal
Resolution: 300 dpi
Print Width: Up to 216 mm
Print Speed: Up to 150 mm/s
Media Types: Paper, cardboard, PET, PE, PP, PI, PVC, PU, acrylate, Tyvek
Label Width: 46 - 220mm
Media Thickness: 0.05 – 0.6 mm
Media Weight: 300 g/m²
Media Roll Diameter: Up to 205 mm
Core Diameter: 38.1 – 76 mm
Ribbon Winding: Ink side out or ink side in
Ribbon Roll Diameter: Up to 80 mm
Ribbon Core Diameter: 25.4 mm
Ribbon Length: Up to 360 m
Ribbon Width: 220 mm
Dimensions (W × H × D): 352 x 288 x 460mm
Weight: 15 kg
Gap Sensor: Labels, perforations, finished materials, marks on translucent media
Reflective Sensor (from below): Labels, finished materials, marks on opaque media
Connectivity: RS232C, USB 2.0 for PC, Ethernet 10/100 Mbit/s, USB Host
Control Panel: 4.3-inch color LCD touchscreen, resolution 272 × 480 px
Power Supply: 100 – 240 VAC, 50/60 Hz, PFC
Power Consumption: <10 W (standby) / 100 W (typical operation) / up to 200 W (maximum)
Operating Temperature / Humidity: +5 – 40°C / 10 – 85% RH, non-condensing
Storage Temperature / Humidity: 0 – 60°C / 20 – 85% RH, non-condensing
