Life: 150000 Cycle
Actuator: Rocker
IP Rating: IP68
Lamp Type: LED
Illuminated: Illuminated
Unit Weight: 46.050 g
Contact Form: DPDT
Panel Cutout: 36.83 mm x 21.08 mm
Mounting Type: Snap In
Terminal Seal: Sealed
Actuator Style: Convex
Current Rating: 20 A
Mounting Style: Panel Mount
Actuator Length: 49.09 mm
Contact Plating: Silver
Switch Function: ON - OFF - ON
Housing Material: Polyester
Actuator Material: Thermoplastic (TP)
Termination Style: Quick Connect (0.250")
Voltage Rating DC: 12 VDC
Illumination Color: Green
LED Supply Voltage: 24 VDC
Flammability Rating: UL 94 V-0
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
