Operating Range (50Hz/60Hz)
12V to 1000V
100V to 1000V
Size(HxWxD): 155mm x 20mm x 22mm
Weight: 48g
General specification
IP67 Water proof & 2m drop-proof
Dual Voltage Sensitivity detector
Red/Yellow/Green LED indicators
Flashlight function
Auto Power Off
Beeper sounds
System self test
Switchable audible and silent mode
Rugged, double molded case
CATIV-1000V
Accessories: Two “AAA” batteries and clamshell
Datasheet
Features: l High power rear flashlight l Thinner probe tip for working with wall outlets l Green LED means power on, flashing red LED with beeper means voltage detected l Low battery selftest & Auto power off l Two modes, green means high voltage mode, yellow means low voltage mode l Forward facing flashlight l Flash and Beep rate increase as the detector gets closer to the voltage source helping the user pinpoint live circuits l Power ON/OFF swith & Silent Mode l Pocket clip for easy storage l CATIV-1000V , IP67 Water proof & 2m drop-proof l ATEX certificate for AC-15Ex/AC-15Exs | ||||||||||||
AC-11 | AC-11B | AC-11S | AC-15 | AC-15B | AC-15S | AC-15Ex | AC-15 Exs | AC-16 | AC-16B | AC-16S | ||
ACV Non-Contact Detection | * | * | * | * | * | * | * | * | * | * | * | |
Operating Range(50Hz/60Hz) | 12V to1000V | * | * | * | * | |||||||
24V to1000V | * | * | * | |||||||||
50V to1000V | * | * | * | * | ||||||||
100V to 1000V | * | * | * | * | * | * | * | |||||
200V to 1000V | * | * | * | * | ||||||||
IP67 Water proof & 2m drop-proof | 2m drop-proof | * | * | * | * | * | * | * | * | |||
Motor Shaking | * | * | * | * | ||||||||
Ex ib IIB T4 (ATEX) | * | * | ||||||||||
Dual Voltage Sensitivity detector | ||||||||||||
Red/Yellow/Green LED indicators | ||||||||||||
Flashlight function | ||||||||||||
Auto Power Off | ||||||||||||
Beeper sounds | ||||||||||||
System self test | ||||||||||||
Switchable audible and silent mode | ||||||||||||
Rugged, double molded case | ||||||||||||
CATIV-1000V | ||||||||||||
Size(HxWxD) | 160 x 20 x 23 | 160mm x 23mm x 25mm | 155mm x 20mm x 22mm | |||||||||
Weight | 60g | 55g | 48g | |||||||||
