Temperature measurement module parameters
Measuring range: 32℃~45℃/89.6°F~113°F
Measurement accuracy: ±0.5℃ / ±0.9℉
Measuring distance: 20~50cm
Measure time: 0.5s
System hardware parameters
Processor: 4-core-A7
Operating system: Android 8.1
Memory size: 1GB LPDDR3
Storage size: 16GB EMMC
Camera parameters
Resolution: Color 200W(1920·1080) Infrared 130w(1280*960)
Imaging device: Color ARO230 Infrared ARO130
Lens: 2.9mm
Recognize height: 1m~2m
Recognition distance: 0.3m~1.2m
Angle of view: Horizontal: 89° Vertical: 57° Diagonal: 98°
Face angle: ±30°
Minimum illumination: Color ≥ 0.01LUX at F1.2 Infrared: ≥ 0.01LUX at F1.2
Signal to noise ratio: Color ≥ 41dB Infrared: ≥ 44dB
Wide dynamic range: Color ≤ 105dB Infrared: ≤83.5dB
Interface parameters
Network interface: 1 RJ45 10M/100M adaptive Ethernet port
USB interface: 1 USB interface
Wireless connection: WIFI+BLE4.0
RS485 interface: 1 RS485 interface
Relay interface: 1 relay interface
Fire alarm door check button: 1 fire alarm door check button
10 reserved: 1 11pin terminal
Power supply: DC12V/3A
Smart functions
Face recognition Capacity: 50000 people
Offline record: 100000
Recognition accuracy: 99.83%
Face liveness detection: Support binocular near infrared live detection
Face detection: 1080P@25fps,support face detection tracking,optimization
Face recognition speed: About 200ms
Face liveness detection speed: About 400ms
Occlusion adaptation: Support wearing glasses,wigs, makeup,etc.,wearing masks
Basic parameters
Screen size: 7 inch
Product size (Length*width* height): 268*135*45(mm)
Operation humidity: 10%~90%
Operation temperature: 10~40℃/50~104℉
