Sensor probe: F / N
Working principle: magnetic induction / Eddy current principle
Measuring range: 0~2000um / 0~2000um
Guaranteed tolerance (of reading): (+/- 2%+2)um / (+/- 2%+2)um
Repeatability: (+/- 1%+1)um / (+/- 1%+1)um
Low range Precision: 0.1um / 0.1um
Minimum curvature radius: 1.5mm / 3mm
Diameter of Minimum area: 7mm / 5mm
Basic critical thickness: 0.5mm / 0.3mm
Size (H x W x D): 120mm x 60mm x 40mm
Weight: 120g
Accessories: Two “AAA” batteries, USB cable, CD, Calibration Iron, Calibration Aluminum, Precision Standard, gift box with carrying case.
