Thickness range: 0.080 mm-635.00 mm (0.003 in.-25.000 in.)
Material velocity range: 0.508 mm/μs-13.998 mm/μs (0.020 in./μs-0.551 in./μs)
Resolution (selectable): Low: 0.1 mm (0.01 in.)
Standard: 0.01 mm (0.001 in.)
High Resolution (optional): 0.001 mm (0.0001 in.)
Transducer frequency range: Standard: 2.0 MHz to 30 MHz (-3 dB)
High Penetration (optional): 0.50 MHz to 30 MHz (-3 dB)
Display: 4” TFT LCD display
Power supply: AC/DC adaptor, 24 V; lithium-ion battery 23.760 Wh; or 4 AA auxiliary batteries
Size(HxWxD): 216mm x 100mm x 47mm
Weight: 706g
Accessories:
3.7V Li battery, USB cable, CD, gift box with carrying case.
