Imaging and optical data
IR resolution: Focal plane array (FPA), uncooled microbolometer: 1024x768
Field of View (FOV): 20°x15°
Spatial resolution (IFOV): 0.51mrad
Thermal sensitivity/NETD: < 0.05°C @ +30°C (+86°F) / 50 mK
Image frequency: 50Hz
Focus: Manual
Laser range finding function: 0.05 to 30m(0.15ft to 98ft)，Typically: ±2mm(±0.06in)
Image presentation
Display: 3.5" 640x480TFT , capacitive touch screen
Image modes: IR image, visual image, picture in picture, AUF, Distance
Color palettes IRON, Rainbow, Grey, Grey Inverted, Brown, Blue-red, hot-cold, Feather, Above alarm, Below alarm, Zone alarm, vision zone
Measurement
Object temperature range:
Low range: –20°C to +150°C (–4°F to +302°F)
High range: 0°C to +650°C (+32°F to +1202°F), Extend to 1500°C (2732°F) (optional)
Accuracy:
Screenning mode: ±0.5°C(±0.9°F) in 32°C to 42°C
±2°C (±3.6°F) or ±2% of reading in –20°C to 650°C
Measurement analysis
Emissivity adjustable: 0.01~1.0 Adjustable
Automatic hot /cold detection: Auto hot or cold spotmeter marks line analyse, area analyse
Set-up
Laser / floodlight: <class2/white LED floodlight
Language selection: English, Chinese, French, German, Spanish, Japanese, Korean, Portuguese, Italian
Storage of videos/images
Storage media: 8Gbytes Micro SD card
Video storage format: Standard MPEG-4, 640x480@30fps, on memory card > 60 minutes
Digital camera
Built-in visible light digital camera: 5M Pixels
Data communication interfaces
USB interfaces: USB-micro, data transform between camera and PC; remote control, live video
Wi-Fi connectivity: Wi-Fi connectivity allows to send images and data to mobile devices remote control, live video
Power system
Battery: Lithium polymer battery, 4 hours operating time
Input voltage: DC 5V
Charging system: AC adapter
Size (HxWxD): 268mm x 100mm x 125mm
Weight: 820g
Accessories: Carrying case, 7.5mm lens, Sun Visor, Tripod base, AC charger/Power supply, Battery, software CD-ROM, Handstrap, micro SD card, USB cable, Gift box
