Input voltage: DC24V ± 5%
Iron generating way: Corona discharge way
Display: LED
H.V (green): High voltage normal operation indicator light is on
ALARM (red): The indicator light is on when discharge is abnormal and electric circuit is abnormal;
CLEANIKIG (yellow): The indicator is on and the buzzer prompts when reaching the set cleaning time.
Voltage regulation mode/ applied voltage: High frequency AC way/±2200V
Ion balance: Within ±20 V(measuring distance 300mm,supply air pressure 0.3MPa)
Destaticizing time: 2.0S(measuring distance 300mm, supply air pressure 0.3MPa)
Cleaning timer set time: Can be set within 0-999 hours
Ozone generation amount (ppm): Within 0.03pp m(measuring distance 50mm,supply air pressure 0.2MPa )
Applicable fluid: Air(cleaning air of which the water and oil has been removed)
Air pressure application range(MPa): 0.01-0.5MPa
Use ambient temperatureIndoor: 0~40°C CM0T
Use ambient humidity: 15~75%Rh (no condensation)
Overall length A (mm): 1373
Installationinterval B (mm): 1286
Installation interval C (mm): 1351.2
Installation interval D (mm): 1358.8
Static elimination (mm): 1320
Electrode spacing F (mm): 1140
