Frequency Range:
DC: 2 Hz ~45 GHz
AC: 10MHz ~ 45GHz
10MHz Precise Frequency Reference
• Frequency accuracy: ± (last calibration date × aging rate + temperature stability + calibration accuracy)
• Aging rate: ± 5×10^-10/day
• Temperature stability: ± 1.5×10^-8
Span
• Range: 0Hz (zero span), 10Hz – the highest frequency of the model
• Accuracy: ± (0.1%× frequency span＋ frequency span/ (sweep points number-1))
Sweep Time Range
• Span≥10Hz: 3us – 16000s
• Span=0Hz: 3us – 16000s
RBW
• 0.1Hz-20MHz (1, 2 ,3 ,5, steps)
• Conversion uncertainty: ±0.10dB; 1Hz to 3MHz (1,2,3,5 steps)
• Conversion uncertainty: ±0.30dB; 5MHz to 20MHz (1,2,3,5 steps)
VBW: 1Hz to 20MHz (1,2,3,5 steps)
Signal Analysis Bandwidth
• Standard: 10MHz
• Option H38-40: 40MHz
• Option H38-200: 200MHz
• Option H38-400: 400MHz
• Option H38-600: 600MHz
• Option H38-1200: 1.2GHz
• Option H38-2000: 2GHz
SSB Phase Noise (Carrier 1GHz, 20℃ -30℃)
Feature
• -107 dBc/Hz @ 100Hz offset
• -125 dBc/Hz @ 1kHz offset
• -134 dBc/Hz @ 10kHz offset
• -136 dBc/Hz @ 100kHz offset
• -142 dBc/Hz @ 1MHz offset
• -152 dBc/Hz @ 10MHz offset
Typical
• -115 dBc/Hz @ 100Hz offset
• -128 dBc/Hz @ 1kHz offset
• -135 dBc/Hz @ 10kHz offset
• -137 dBc/Hz @ 100kHz offset
• -140 dBc/Hz @ 1MHz offset
• -154 dBc/Hz @ 10MHz offset
Trigger Source: Free, Line, video, external 1, external level 2, burst RF, timer
Trigger Detector: Normal, positive peak, negative peak, sample, video average, power average, voltage average
Residual Response: ≤-98dBm; 1MHz ≤ f ≤8GHz; RF Port 1
Power Supply: AC 100 – 240V: 50 – 60Hz
Dimension: Excluding the handle, brackets: (426±4）mm × (222±4）mm × (450±4）mm
Weight: About 35kg (different configuration cause different weight)
See more detail information in the Datasheet
