Sensor: Ion flow humidity sensor
Measurement range: O2:0~25.00%,H2O:0~40.00%
Measurement accuracy:
0~1% O2 ±3%FS
1~25% O2 ±3%R
0~40.00% H2O ±2%FS
Repeatability:
0~1% O2 ±1.5%FS
1~25% O2 ±1.5%R
0~40.00% H2O ±1%FS
Stability:
0~1% O2 ±1.5%FS/7d
1~25% O2 ±1.5%R/7d
0~40.00% H2O ±1%FS/7d
Response time: T90≤30s(Fully Preheated)
Power supply: 85~264VAC,50/60Hz
System power consumption: Not greater than 30VA
Communication: RS485 (standard)/RS232 (optional)
Sensor life: Greater than 2 years (normal use)
System life Greater than 5 years (normal use)
System usage ambienttemperature: -10~50°C
Probe ambient temperature: 0~500°C
Measurement method: ejection
System cabinet installation: Wall-mounted
System cabinet installation dimensions: L×W=560mm×360mm
Probe installation: flange installation
