Sensor: Zirconia concentration cell sensor
Measure range: 0~25.00% O2
Accuracy:
0.01~99.9 ppm: ±5ppm
100~999.9ppm: ±3%FS
1000~9999 ppm:±3%FS
1.00%~25.00%: ±3% of the measured value
Repeatability:
0.01~99.9 ppm: ±2.5ppm
100~999.9ppm: ±1.5%FS
1000~9999 ppm:±1.5%FS
1.00%~25.00%:±1.5% of the measured value
Stability:
0.01~99.9 ppm: ±2.5ppm/7d
100~999.9ppm: ±1.5%FS/7d
1000~9999 ppm:±1.5%FS/7d
1.00%~25.00%:±1.5% of the measured value/7d
Response time: T90<20s (after full preheating)
Power supply: 24VDC
Transmitter power: <25VA
Weight: about 1.05kg
Calibration point: Recommendations:20.60%,1%,500ppm, 50ppm,10ppm
1 set,4-20mA/0-20mA/0-1V/0-5V/0-10V/ 1-5V,(You can set the mode freely).
Environment temperature: -10~+50°C Environment Humidity:<80%RH
Sample gas pressure: atmospheric conditions±10% (Gas outlet should be atmospheric conditions)
Storage environment: -10~+50°C,environmental humidity less than 90%RH,no condensed water.When the storage and transportation environment temperature is lower than 5°C,the transmitter should be placed in the normal working temperature environment for more than 4 hours before use.
