General functions
- Display: Multi-display backlit LCD
- Types of installations: Single-phase
- Number of channels: 1V/1I
- Network frequency: 50 and 60 Hz
- Voltage: 10 V to 690 V
- Ratios: Yes
- Power/energy values: P, Pf, N, S, Qf, D / Up to 4 Exa
- Min – Max: Yes
- THD: Yes
Additional functions
- Acquisition rate : 1 measurements / s
- Aggregation: 1 min to 60 min
- Storage mode: SD / SD-HC card; 8 GB (expandable to 32 GB)
- Ethernet : Yes (via simplified Wifi)
- Safety: IEC 61010 CAT III 600 V
- Power supply: Via the measurement phase (90 – 690 V)
- Battery: NiMH – Battery life 1 hour
- Dimensions: 180 x 88 x 87 mm
- Weight: 400 g
- Casing: IP54
