Functions: AC, DC, IR
AC Withstanding Voltage
Output Voltage Range: 0.05 ~ 5kV
Load Regulation: ≦(1% + 5V)
Output Voltage Resolution: 2V
Output Voltage Accuracy: ±(1% of reading + 5 counts)
DC Withstanding Voltage
Output Voltage Range: 0.05 ~ 6kV
Output Voltage Resolution: 2V
Output Voltage Accuracy: ±(1% of reading + 5 counts)
Insulation Resistance (IR)
Output Voltage: 0.05 ~ 1kV
Output Resolution: 2V
Output Voltage Accuracy: ±(1% of reading + 5 counts)
IR Range: 1MΩ ~ 10GΩ
Interface: RS232 (standard), GPIB (optional)
Power Supply: 100V / 120V / 220V / 240V (AC ±10%), 50/60Hz
Dimensions: 320 x 105 x 400 mm
Weight: 15.4 kg
