CHROMA 61607 Programmable AC Power Source (3kVA)

AC Output

Number of output phases: 1 phase or 3 phase

Max power: 3kVA

Power per phase: 1kVA

Voltage

Voltage range: 0~175V/0~350V/Auto

- Accuracy: 0.1% of RD+0.2% of FS

- Resolution: 0.1V

- Distortion:

+ < 0.3% @50/60Hz ;

< 1% @15Hz ~ 500Hz ;

1% maximum to 500Hz, add 0.5%/kHz up 2kHz

Line regulation: 0.1%

Load regulation: 0.2%

Maximum Current (Single-phase mode)

RMS: 30A/15A

Peak (CF=4): 120A/60A

Maximum Current (Per phase in three-phase mode)

RMS: 10A/5A

Peak (CF=4): 40A/20A

Frequency

Frequency range: 15Hz~2000Hz

Accuracy: 0.01%

DC Output (Single-phase mode)

Power: 3kW

Voltage: 247.5V/495V

Current: 30A/15A

DC Output (Three-phase mode)

Power: 1kW

Voltage: 247.5V/495V

Current: 10A/5A

Input Specifications:

Voltage range: 3Ø 200-240V±10%VLN (WYE) ; 3Ø 200-240V±10%VLL (Delta)

Current (per phase): 15A Max./Phase (3Ø 200-240V±10%VLL)

Power factor: 0.97 (Typical)

Measurement

Voltage

Voltage range: 0~175V/0~350V/Auto

Voltage accuracy: 0.1% of RD+0.2% of FS

Current

Current accuracy (RMS): 0.2% of RD+0.2% of FS

Current accuracy (Peak): 0.2% of RD+0.4% of FS

Power

Accuracy: 0.2% of RD+0.4% of FS

Programmable impedance: 0Ω+0.2mH ~ 1Ω+2mH

Efficiency: >80%(Typical)

Protection: OVP, OCP, OPP, OTP, FAN

Safety & EMC standards: CE mark

Dimensions (H x W x D): 221.5 x 425 x 680mm

Weight: 50 kg
