Width: 64 mm (2.52 in)
Height: 34.5 mm (1.358 in)
Length: 91.4 mm (3.598 in)
Industry: Medical
Approvals: Class I, Class II, EN60601-1, IEC60601-1, UL ANSI/AAMI ES60601-1
Compliance: Class I, Class II, EN60601-1, IEC60601-1, UL ANSI/AAMI ES60601-1
Efficiency: 94 %
Unit Weight: 218 g
Output Power: 130 W
Input Voltage: 80 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Power - Convection: 100 W
Power - Forced Air: 130 W
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 2.7 A
Output Voltage-Channel 1: 48 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 30 C
