Image Type: Monochrome and color
Storage: 7.2 GB on board + 8 GB on SD card
RAM: 512 MB SDRAM
Sensor Type: CMOS, global shutter
Resolution: 640 x 480/ 800 x 600
Acquisition Rate: Monochrome: 217/165 | color: 135/100
HDR support: No
Lenses: C-mount, S-mount/M12, Autofocus
Lighting: Internal light, DataMan 360 light, external light powered by In-Sight or external light independent power
Internal lighting color: Red, white, IR, or blue
Built-in I/O: 1 dedicated trigger in, 1 input, 2 outputs, 2 bi-directional/configurable, and RS-232. Additional I/O available via external I/O modules: CIO-MICRO or CIO-1400
Power Supply: 24 VDC
Standard: IP67 with included cable and lens cover
Network communication: 1G (1000)/100/10 Mbps
Industrial Protocols: OPC UA, EtherNet/IP with AOP, PROFINET Class B, iQSS, CC-Link IE Field Basic, SLMP/SLMP Scanner, Modbus TCP, IEEE 1588 (CIP Sync)
General Protocols: TCP/IP, UDP, FTP, SFTP, Telnet, SMTP, RS-232
