Width: 17 mm
Height: 10.8 mm
Length: 17 mm
Shielding: Shielded
Inductance: 60 uH
Application: MAX17498B Evaluation Kit
Unit Weight: 7.100 g
Core Material: Ferrite
Current Rating: 1.5 A
Frequency Range: 500 kHz
Isolation Voltage: 3.5 kV
Termination Style: SMD/SMT
Maximum DC Current: 1.5 A
Number of Channels: Single
Primary Resistance: 110 mOhms
Secondary Resistance: 35 mOhms
Maximum DC Resistance: 170 mOhms, 35 mOhms, 110 mOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
