Wetted Parts : Copper alloy, Glass-Ølled PA66, Gas phase Rubber , PTFE, TPU, HDPE, Acetal
Free-Air Capacity (CFM) : 0.31
Free-Air Capacity (LPM) : 8.8
Free-Air Capacity (LPH) : 526.7
Max Pressure (PSI) : 33
Max Pressure (bar) : 2.27
Max Vacuum (in Hg) : 21.3
Max Vacuum (mbar) : 721.3
Max Vacuum (mm Hg) : 541
Max Vacuum (torr) : 541
Port Size : 1/4\" hose barb
Max Temperature (° F) : 104
Max Temperature (° C) : 40
Duty Cycle : Continuous
Power (VAC) : 230
Power (amps) : 1.5
Power (Hz) : 50
Motor Type : Shaded pole
Height (in) : 8.52
Width (in) : 7
Length (in) : 9
Height (cm) : 21.65
Width (cm) : 17.87
Length (cm) : 23.05
Height (mm) : 216.5
Width (mm) : 178.7
Length (mm) : 230.5
Motor hp : 1/11.5
