Max. Capacity: 5kN
Units: Force: gf, kgf, lbf, N, kN, ozf, tonf(SI), ton(long), tonf(short); Pressure: Kpa, Mpa, psi, bar, mm-Aq, mm-Hg
Force Precision: 1/100,000
Force Resolution: 31 bits
Test stroke: 800mm (w/o grip)
Stroke resolution: 0.0001mm
Cantilever distance: 70 mm
Speed range: 0.0002 ~ 830 mm/min adjustable（Set up by computerized）
Speed accuracy: High speed mode: 0.05 ~ 830 mm/min; Low speed mode: 0.0002~3 mm/min
PC-Port:RJ45(TCP/IP)(Connect software optional)
Data sampling rate:1200Hz (Max.)
Hardware safety protection: upper limit, lower limit, emergency stop
Motor type: Servo Motor
Stiffness Slop:1585kgf/mm
Power Supply:Single phase 200~240 V, 5 A
Dimension: 50 × 53 × 145 cm
Weight: 80kg
Option:
- Display panel: EM2FTP-001 or Software: SM2F0-04 or all (nessesary)
- Long extensometerQC-557
- Grips (nessesary)
