Max. Capacity: 5kN
Force Precision: 1/10,000
Force Resolution: 1/100,000
Testing space:Ø70mm
Test stroke: 400 mm
Stroke resolution: 0.0002 mm
Cantilever distance: 70 mm
Speed range/ force: 20~35 mm/min 200kg
Speed range/ force: 35~600 mm/min 500kg
PC-Port: TCP/IP
Data sampling rate:1200Hz
Hardware protection device: upper limit, lower limit, emergency stop
Motor type: DC motor
Power Supply:Single phase 100 ~ 240 V
Dimension: 50 x 53 x 145 cm
Weight: 80kg
Includes: display unit
Option:
- Grips (nessesary)
- Software
- Long extensometerQC-557
- Loadcell. If want to test under 10% Max. Capacity
