Width: 7.62 mm
Height: 2 mm
Length: 7.62 mm
Pushing: 1 MHz/V
Frequency: 559 MHz to 561 MHz
Power - dBm: 1 dBm
2nd Harmonic: - 15 dBc
Current Rating: 25 mA
Mounting Style: SMD/SMT
Load Capacitance: 100 pF
Phase Noise Type: - 105 dBc/Hz
Termination Style: SMD/SMT
Tuning Sensitivity: 12 MHz/V
Supply Voltage - Max: 5.25 V
Supply Voltage - Min: 5.25 V
Tuning Voltage Range - Vt: 500 mVDC to 5 VDC
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
