Size
Inner(W x D x H)mm: 1500x578x676
Out(W x D x H)mm: 1570x788x2080
Weight: 250
Base Stand(H)mm: Stand 705(Included Caster 82)
Type: Class A2 (70% recirculation as downflow & 30% exhaust as outflow)
Controller:
Display: Back light LCD display
Function: FL lamp On/Off, UV lamp On/Off, UV lamp timer, Total using / Filter using time
Door
Weight balanced sliding tempered safety glass(5mm thick)
Worktop Material: Stainless steel plate 304, HL
Inside Material; Stainless steel plate 304, HL
Outside: Epoxy powder coated steel plate
Filter: H-14 HEPA filter : 99.995% at 0.3 / ISO class 5
Average Airflow Velocity:
Inflow: 0.45 m/s ± 0.025 m/s
Downflow: 0.45 m/s ± 0.025 m/s
Gas Valve: 1EA
Air valve: 1EA
Consent: 2EA with reinforced cover(mounted on inside wall)
UV lamp: 30W x 1EA
FL Lamp: 55W x 2EA
Noise (dB): < 65dBA
Power: AC 230V ± 10%, 50-60Hz, 1Phase
Safety: UV lamp automatic switch-off when door's opened, Fuse installed each electric part,
Filter life span alarm with buzzer and display on screen
Optional Accessories:
Filter
Pressure gauge
