Width: 115 mm (4.528 in)
Height: 30 mm (1.181 in)
Length: 215 mm (8.465 in)
Industry: Industrial
Approvals: IEC/EN60950-1, UL60950-1
Compliance: IEC/EN 60950-1, UL 60950-1
Efficiency: 89 %
Unit Weight: 1 kg
Output Power: 252 W
Input Voltage: 90 VAC to 132 VAC, 180 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 1.5 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 10.5 A
Output Voltage-Channel 1: 24 VDC
Operating Temperature Range: - 20 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
