Width: 76.2 mm
Height: 35.1 mm
Length: 127 mm
Industry: Medical
Approvals: EN60601-1, IEC60601-1, UL/cUL60601-1
Compliance: EN 60601-1, IEC 60601-1, UL/cUL 60601-1
Efficiency: 92.5 %
Unit Weight: 410 g
Output Power: 300 W
Input Voltage: 90 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVrms
Number of Outputs: 1 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 25 A
Output Voltage-Channel 1: 12 VDC
Operating Temperature Range: - 40 C to + 80 C
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 40 C
