Resistance: 0.1Ω
Bandwidth (-3dB): 2GHz
Rise time: ≤175ps
Maximum continuous power: 2W
Temperature coefficient of resistance/℃: ±40ppm
Weight: 26g
Maximum pulse energy that can be sustained: 1J
Coaxial shunt diameter: 10mm
Coaxial shunt length: 78mm
Wire type input pin size: Diameter 1.5mm/length 15mm
Bolt type input bolt size: Bolt diameter M3/length 15mm
PCB copper foil with bolt type contact: 10mm diameter conductive ring
Signal output connector: BNC
Maximum torque of fixed nut: 0.5 N* m
