Pressure Measurement
Gauge Pressure: -100KPa ~ 0 ~ 250MPa (each level)
Differential Pressure: -100KPa ~ 0 ~ 2.5MPa (each level)
Absolute Pressure: 0 ~ 110KPa (each level)
Main Pressure Range Measurement Accuracy: 0.1%F·S; 0.05%F·S; 0.02%F·S
Voltage Measurement
Measurement: Each range within 0-30V, the accuracy of the 0-5V range is ±(0.005% RD+0.005% FS), input impedance: >5MΩ.
Output: 0-15V, Accuracy: ±(0.005% RD+0.005% FS)
Output impedance:<1Ω
Working Environment: Temperature 5 ～ 50℃ , humidity <90%.
Size: Φ120mm*195mm
Weight: about 2kg.
Current Measurement
Measurement: 0 ～ 30mA, accuracy: ±(0.005% RD+0.005% FS), input impedance: 5Ω (plus fuse resistance).
Output: 0-30mA
Accuracy: ±(0.005% RD+0.005%FS).
Power Supply:
The rechargeable battery inside the machine is 9V, power consumption: <0.6W.
External power supply: 220V, 50Hz.
