- Condenser Type: Diagonal-type
- Bottle Capacity:
Evaporating: Included 2x Evaporating Flasks: 1x0.5Lit & 1 x 1 Lit; Available 100-/250-ml, 2 Lit Evaporating Flask ( Optional)
Reveiving: Included 1ea 1 Lit Flask
- Rotary Speed: 10 ~ 180 rpm
- Evaporating Capability: 20 ml/min
- Cooling Surface: 1300cm2
- Achievable Vacuum: 399.9Pa(below 3mmHg)
- Bath Capacity: 6.5 Lit. / Φ254×130 mm
- Temp. Range: 0℃ ~ 100℃
- Elevating Stroke: 100 ~ 250 mm
- Vacuum Sealing: Double Sealing Rings made of Teflon+Vinton Materials
- Power Consumption: Motor : 25 W, Heater : 1.05KW
- Controller & Display: PID Controller, Digital display
- Dimension & Net Weight: 750x320xh540mm/ 9.5kg
- Power Supply: AC 220V,50/ 60Hz or AC110V, 60Hz
