Measuring Range: 0.63 – 500mm
Stainless steel
MeasuringResolution : 0.001 inch (0.01 millimeter)
Units : Inches/Millimeters/Microseconds/metters-second
1 to 10 MHz frequency range.
Velocity Range: .0492 to .3937 in/m s. 1250 to 10,000 meters/sec
Velocity Settings: The MX-1 has 1 custom velocity setting programmed via a PC.
RS232 conect to PC and PC Software
Size: 2.5 W x 4.75 H x 1.25 D inches
63.5 W x 120.7 H x 31.8 D mm
Weight: 10 ounces
Operating Temperature: -20 to 120F (-20 to 50C
Two 1.5V alkaline or 1.2V NiCad AA cells.
Typically operates for 200 hours on alkaline and 130 hours on NiCad.
Logger 100 data
