Measurement Range:
PE: 0.63 - 500mm (0.025 - 19.999”)
EE (ThruPaint™): 2.54 - 102mm (0.100 - 4.000”)
PECT: 0.63 - 500mm (0.025 - 19.999”)
PECT: 0.01 - 2.54mm (0.001 - 0.100”)
EEV (ThruPaint™): 1.00 - 152mm (0.040 - 6.000”)
Measurement Resolution: 0.01mm (0.001”)
Velocity Calibration Range: 1250 to 13995m/s (0.0492 to 0.5510in/µs)
Operating Temperature: -29 to 60ºC (-20 to 140ºF)
Power Supply: 3 x AA batteries
Battery Life: 50 hours on alkaline and 20 hours on NiCad (backlight off); 15 hours on alkaline and 8 hours on NiCad (backlight on)
Gauge Weight: 680g (24.0oz) - including batteries
Gauge Dimensions: 229.0 x 60.33mm (9.0 x 2.4”)
Packing List: Unit; Selectable Transducer; Couplant; Manual; Plastic Carrying Case; Certificate of Calibration and AA Batteries. PC Software and Data Transfer Cable included with data logging gauges.
