Measuring range:
- Conductivity (full range automatic switching): 0.00~20.000μS/cm
- Resistivity MΩ.cm: 0.00 ~18.00 MΩ.cm
- TDS(mass-volume concentration mg/L): 0.00 ~10g/L
- Salinity (mass concentration ‰): 15ppt
- Temperature (Celsius): -10～150℃
Resolution:
- Conductivity: 0.001μS/cm
- Resistivity:0.01MΩ.cm
- TDS(mass-volume concentration mg/L): 0.01mg/L
- Salinity (mass concentration‰): 0.01%
- Temperature(Celsius):0.1℃
Accuracy:conductivity/temperature ±1.0% FS/0.5℃
Repeatability: Better than ±0.3%F.Sof the measuring range
Display screen: 3.2 inches black and whitegraphic LCD display; 128*64dot matrix LCD
Relay output: 2 configurable SPST relays, maximum load 3A/250VAC
water proof grade: IP66
Operating environment:0～60℃
Storage environment:-20～70℃
Instrument shape:100*100*120mm
Installation opening:92*92mm
Installation method: cabinet panel installation
Shell Material: Reinforced ABS
Electrical interface: 3 M12*1.5 Glen heads are reservedat the back end of the instrument;the wire diameteris 3~6.5mm
Maximum power:3W
Temperature unit: NTC10K(support customization)
Current output:2-way 0/4~20mA active current loop can be set, load 1000 ohm, support long-term calibration
Digital communication interface: 1-way two-wire RS485 interface, MODBUS RTU
Power: DC:+18~36VDC 2 electrodes
