Response Time: T90＜10s
Calibration Method: Zero position calibrationand slopecalibration
Work Pressure: ≤4Bar
Sample Flow: Rate 0.5m/s≥flow rate≥0.001m/s
Operating Temp:0~50℃ (does not freeze)
Storage Temp: 0~60℃ (does not freeze)
Shell Material: ABS or PPS
Dimension Diameter: 35mm, Length:220 mm (protective claw included)
Protection Grade: IP68
Power Supply: 9~24VDC
Power Consumption: 0.2W
Weight: 200g
Cable: Standard 5 meters(other length can be customized)
Measuring Object: ORP
Measuring Technology: Electro chemicapl latinum electrodes
Measuring Range: ORP: ±2000mV, TEMP:0~50℃
Resolution:1mV/ 0.1℃
Accuracy: 0.1% of the range or ±2mV, take the larger one; Temp: ±0.5℃
Communication: RS485 MODBUS-RTU
Temp Unit: Temp measurement
