Channel Configuration
Channel number: 20
Channel characteristics: Multifunction channel
Channel function: TC、RTD、Humidity Sensor & Other types of voltage output sensors
Channel technical indicators
Range: Measuring range/ Resolution/ Accuracy/ Remarks
100mV: -10mV ~ 100mV/ 0.1uV/ 0.01%+0.008%/ Themocouple module
100Ω: 0Ω ~ 100Ω/ 0.1mΩ/ 0.02%+0.02%/ PRT module
Technical index of temperature and humidity
Type: Measuring range
K: -200℃ ~ 1300℃
J: -200℃ ~ 900℃
T: -200℃ ~ 400℃
E: -200℃ ~ 1000℃
N: -200℃ ~ 1300℃
B: 250℃ ~ 1820℃
R: 0℃ ~ 1768℃
S: 0℃ ~ 1768℃
Pt100: -200℃ ~ 800℃
Humidity: 0%RH ~ 100%RH
Sampling rate: 0.2s/24 channel
Sampling speed: 24 channels of simultaneous sampling; This ensures that the data is fully synchronised in real time.
General technical indicators
Power requirement: 12V DC 2A
Communication interface: RS232, LAN, Wireless
Shell material: alufer +ABS
Appearance size: 250mm×140mm×100mm
Instruments weight: 2 kg
Environment:
Use: (5 to 35)℃, (0 to 85）%RH
Store: (0 to 70)℃, (0 to 100）%RH
