Operating Environment
Input Power: 220V±10% 50Hz±10%
Atmospheric Pressure: 80 - 106 kPa
Temperature: -10 - 40°C
Humidity: ≤50%RH
Safety Performance
Insulation Resistance: >2kΩ
Dielectric Strength: 1.5kV power frequency withstand voltage for 1 minute (No flashover or arcing)
Basic Parameters
Time (200ns range): 200.00ns (±0.01ns±2 digits)
Resolution: 0.01ns
Time (2000ns range): 2000.0ns (±0.1ns±2 digits)
Resolution: 0.1ns
Time (20000ns range): 20000ns (±1ns±2 digits)
Resolution: 1ns
Speed (0 - 2m/s): 20.00m/s (±0.1m/s±1 digit)
Resolution: 0.01m/s
Speed (>2m/s): 20.00m/s (±0.2m/s±1 digit)
Resolution: 0.01m/s
Stroke Parameters
Vacuum Circuit Breaker: 50.0nm
Resolution: 0.1nm
SPB Circuit Breaker: 300.0nm
Resolution: 1nm (±0.1nm±1 digit)
Oil - Immersed Circuit Breaker: 600.0nm
Resolution: 1nm (±0.1nm±1 digit)
