Color: Black
Pitch: 10.01 mm (0.394 in)
Width: 40.51 mm
Gender: Receptacle (Female)
Height: 31.75 mm
Length: 43.13 mm
Dimensions: 40.51 mm x 31.75 mm x 43.13 mm
Insulation: Insulated
Application: Wire to Wire
Unit Weight: 10.740 g
REACH - SVHC: Details
Mating Gender: Plug
Contact Gender: Pin (Male)
Current Rating: 13 A
Housing Gender: Receptacle (Female)
Mounting Angle: Straight
Mounting Style: Mounting Flange
Voltage Rating: 250 V
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 14 AWG to 20 AWG
Locking Mechanism: Integrated in Housing
Termination Style: Crimp
Ingress Protection: IP68, IP6K9K
Mating Part Number: DT06-3S
Number of Positions: 3 Position
Attachment Hole Diameter: 1.5 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
