Color: Gray
Pitch: 4 mm, 6 mm
Width: 43.75 mm
Gender: Receptacle (Female)
Height: 37.3 mm
Length: 76.5 mm
Application: Wire to Board/Device
Row Spacing: 1.5 mm
Contact Gender: Without Socket Contacts
Mounting Angle: Right Angle
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 4 Row
Voltage Rating: 42 VDC
Wire Gauge Max: 12 AWG
Housing Material: Polybutylene Terephthalate (PBT)
Locking Mechanism: On the terminal
Termination Style: Crimp
Ingress Protection: IP69K
Flammability Rating: UL 94 V-0
Number of Positions: 29 Position
Maximum Operating Temperature: + 120 C
Minimum Operating Temperature: - 40 C
