Color: Black
Pitch: 4.45 mm (0.175 in)
Width: 20.83 mm
Gender: Plug (Male)
Height: 19.58 mm
Length: 32.46 mm
Material: Plastic
Dimensions: 20.83 mm x 19.58 mm x 32.46 mm
Insulation: Insulated
Application: Wire to Wire
Row Spacing: 9.12 mm
Unit Weight: 9 g
REACH - SVHC: Details
Mating Gender: Receptacle
Contact Gender: Socket (Female)
Current Rating: 13 A
Housing Gender: Plug (Male)
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Voltage Rating: 250 V
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 14 AWG to 20 AWG
Locking Mechanism: Integrated in Housing
Termination Style: Crimp
Ingress Protection: IP68, IP6K9K
Mating Part Number: DT04-4P
Number of Positions: 4 Position
Attachment Hole Diameter: 1.5 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
