Color: Black
Pitch: 4.19 mm (0.165 in)
Width: 12.07 mm
Gender: Plug (Male)
Length: 27.56 mm
Material: Plastic
Dimensions: 12.07 mm x 12.9 mm x 27.56 mm
Insulation: Insulated
Unit Weight: 3.150 g
REACH - SVHC: Details
Mating Gender: Receptacle
Contact Gender: Without Socket Contacts
Current Rating: 7.5 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 1 Row
Voltage Rating: 250 V
Wire Gauge Max: 16 AWG
Wire Gauge Min: 20 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 16 AWG to 20 AWG
Termination Style: Crimp
Mating Part Number: DTMH04-2PD, DTM04-2PD
Number of Positions: 2 Position
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
