Color: Gray
Gender: Receptacle (Female)
Height: 36.5 mm
Length: 42.18 mm
Material: Plastic
Dimensions: 36.5 mm x 36.5 mm x 42.18 mm
Insulation: Insulated
Application: Wire to Wire
Unit Weight: 38.300 g
REACH - SVHC: Details
Mating Gender: Plug
Contact Gender: Without Pin Contacts
Current Rating: 13 A
Mounting Angle: Straight
Mounting Style: Mounting Flange
Voltage Rating: 250 V
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Housing Material: Plastic
Wire Gauge Range: 14 AWG to 20 AWG
Termination Style: Crimp
Ingress Protection: IP68, IP6K9K
Mating Part Number: HD16-9-96SX-XXXX
Number of Positions: 9 Position
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
