Width: 50.8 mm
Gender: Receptacle (Female)
Height: 47.53 mm
Length: 68.5 mm
Material: Aluminum
Dimensions: 50.8 mm x 47.53 mm x 68.5 mm
Application: Wire to Wire
Unit Weight: 89.793 g
Contact Gender: Without Socket Contacts
Current Rating: 25 A, 60 A, 100 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 250 V
Wire Gauge Max: 6 AWG
Wire Gauge Min: 20 AWG
Housing Material: Aluminium
Wire Gauge Range: 6 AWG to 20 AWG
Locking Mechanism: Integrated in Housing
Termination Style: Crimp
Ingress Protection: IP67
Mating Part Number: HD36-24-XXXX
Number of Positions: 9 Position
Attachment Hole Diameter: 6 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
