Color: Black
Width: 49.53 mm
Gender: Plug (Male)
Length: 42.55 mm
Material: Plastic
Dimensions: 49.53 mm x 49.53 mm x 42.55 mm
Unit Weight: 62 g
REACH - SVHC: Details
Mating Gender: Receptacle
Contact Gender: Without Socket Contacts
Current Rating: 13 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 250 V
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 14 AWG to 20 AWG
Locking Mechanism: Integrated in Housing
Termination Style: Crimp
Ingress Protection: IP67
Mating Part Number: HDP24-24-31
Number of Positions: 31 Position
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
