Color: Black
Pitch: 3 mm, 3.4 mm, 5.8 mm, 6.1 mm
Width: 38.9 mm
Gender: Plug (Male)
Height: 48.5 mm
Length: 81 mm
Material: Plastic
Dimensions: 38.9 mm x 48.5 mm x 81 mm
Insulation: Insulated
Row Spacing: 10.85 mm, 11.35 mm, 3.5 mm
Unit Weight: 90 g
Mating Gender: Receptacle
Contact Gender: Without Socket Contacts
Current Rating: 7.5 A, 13 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 4 Row
Voltage Rating: 48 V
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Housing Material: Polybutylene Terephthalate (PBT)
Wire Gauge Range: 14 AWG to 20 AWG
Termination Style: Crimp
Ingress Protection: IP68, IP6K9K
Mating Part Number: SRK02-MDB-32A-001
Number of Positions: 32 Position
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
