Color: Black
Width: 43.17 mm
Gender: Plug (Male)
Height: 43.17 mm
Dimensions: 43.17 mm x 43.17 mm x 38.63 mm
Insulation: Insulated
Application: Wire to Wire
Unit Weight: 136.080 g
REACH - SVHC: Details
Mating Gender: Receptacle
Contact Gender: Without Socket Contacts
Current Rating: 13 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 250 V
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 14 AWG to 20 AWG
Locking Mechanism: Integrated in Housing
Termination Style: Crimp
Ingress Protection: IP67
Mating Part Number: HDP24-18-14PE-C041
Number of Positions: 14 Position
Attachment Hole Diameter: 4 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
